EZG Manufacturing GPM4X8 8' x 4' Hogtrax Ground Protection Mat
EZG Manufacturing GPM4X8 8' x 4' Hogtrax Ground Protection Mat
EZG ManufacturingContact your sales representative or store for pricing and more information
(No reviews yet)
EZG Manufacturing GPM4X8 8' x 4' Hogtrax Ground Protection Mat
Get Maximum Traction with Minimal Impact.
Introducing EZG ground protection mats specifically engineered for large equipment use on susceptible surfaces. EZG Hogtrax features a robust diamond cleat over honeycomb dual-surface tread design for aggressive grip, while preventing ruts, and establishing stable pathways.
- Capable of supporting weights up to 120 tons* per mat.
- Four hand holds per mat for easy manual mobilization and positioning.
- High-density polyethylene material ensures resistance to rot, splintering, warping and breakage.
- Effortless multi-mat connectivity for assembling temporary roads or functional platforms.
SPECIFICATIONS
Model #: GPM4x8
Dimensions: 48" x 96" (1219 x 1438 mm)
Thickness: 1/2 inch (13 mm)
Tread Depth: .273" (7 mm)- Diamond
.149" (4 mm)- Honeycomb
Hand Holds: 4 (centered on 4 sides)
Approx Area: 32 sq.ft. (3 m2)
Compressive Strength (5% strain): 2350 psi (16.2 MPa) @ 73.4˚F (23˚C)
Working Load*: 120 tons (120,000 kg)
Weight: 92 lbs. (42 kg)
* load limit based on application
