W.R. Meadows Air-Shield 75-Foot Roll - Self-Adhering Air/Vapor and Liquid Moisture Barrier
AIR-SHIELD self-adhering air/vapor and liquid moisture barrier is part of a total W. R. MEADOWS system to complete the building envelope. It is a roll-type product that is nominally 40 mils thick. The membrane’s controlled thickness is fabricated from cross-laminated polyethylene bonded to specially modified asphalt.
This unique, self-adhesive membrane, protected by a special release paper, is strong and durable. It remains flexible when surface mounted and will adhere to most primed surfaces at minimum temperatures of 40° F (4° C). The membrane provides excellent protection as a tough barrier that won’t shrink, sag, dry out, crack, or rot. It offers excellent resistance to punctures during installation. AIR-SHIELD can also be used as a transition membrane to provide protection against water infiltration in critical detail areas, such as window and door openings, deck-to-wall intersections, corner boards, wall-to-wall tie-ins, foundation sill plates, sheathing panel seams, under stucco finishes, masonry walls, and other non-roof detail areas.
USES
AIR-SHIELD self-adhering air/vapor and liquid moisture barrier is designed for a variety of uses.
Primary applications include cavity wall and masonry wall construction. AIR-SHIELD works equally well as an air and/or vapor barrier on precast concrete, cast-in-place concrete, masonry (concrete block), interior and exterior gypsum board, Styrofoam, primed steel, aluminum mill finish, anodized aluminum, primed galvanized metal, drywall, and plywood.
SPECIFICATIONS
- Exceeds the requirements of the Massachusetts Commercial Energy Code for Building Envelope Systems.
- Meets CAN/CGSB-51-33, Type I Water Vapor Permeance Requirements.
- ABAA Section 07261 Self-Adhering Air and Vapor Barrier Specification
Sizes
MD4506 - 6" x 75' Roll
MD4509 - 9" x 75' Roll
MD4512 - 12" x 75' Roll
MD4516 - 16" x 75' Roll
MD4518 - 18" x 75' Roll
MD4524 - 24" x 75' Roll
