Simpson STB2-50334Strong-Bolt 2 Anchor 1/2 Inch X 3-3/4 Inch (Studs) 25 Piece Box
Simpson STB2-50334Strong-Bolt 2 Anchor 1/2 Inch X 3-3/4 Inch (Studs) 25 Piece Box
Simpson Strong TieContact your sales representative or store for pricing and more information
(No reviews yet)
Simpson STB2-50334Strong-Bolt 2 Anchor 1/2 Inch X 3-3/4 Inch (Studs) 25 Piece Box
Code listed for cracked and uncracked concrete, and masonry applications, the Strong-Bolt 2 wedge-type expansion anchor is an optimal choice for high-performance even in seismic and high-wind conditions. Dual undercutting embossments on each clip segment enable secondary expansion should a crack form and intersect the anchor location; this feature significantly increases the ability of Strong-Bolt 2 to carry load if the hole expands.
Key Features
- Chamfered top designed to prevent mushrooming during installation
- Qualified for static and seismic loading conditions (seismic design categories A through F)
- Suitable for horizontal, vertical and overhead applications
- Qualified for minimum concrete thickness of 3 1/4", and lightweight concrete-over-steel deck thickness of 2 1/2" and 3 1/4"
- Standard (ANSI) fractional sizes: fits standard fixtures and installs with common drill bit and tool sizes
- Tested per ACI355.2 and AC193
Material
- Zinc-plated carbon steel or stainless steel (Type 304; Type 316)
