Honda GX160UT2QX2 5.5 HP Honda Engine
Honda GX160UT2QX2 5.5 HP Honda Engine
Honda EnginesContact your sales representative or store for pricing and more information
Honda GX160UT2QX2 5.5 HP Honda Engine
Quality and performance come standard.
Honda's GX series engines are legendary for superior reliability and performance. And there's no doubt about it: the GX160 lives up to the legend. Lower noise levels, lower vibration, and lower emissions – without sacrificing power output or performance.
| Engine Type | Air-cooled 4-stroke OHV |
| Bore x Stroke | 68 X 45 mm |
| Displacement | 163 cm3 |
| Net Power Output* | 4.8 HP (3.6 kW) @ 3,600 rpm |
| Net Torque | 7.6 lb-ft (10.3 Nm) @ 2,500 rpm |
| PTO Shaft Rotation | Counterclockwise (from PTO shaft side) |
| Compression Ratio | 9.0 : 1 |
| Lamp/Charge coil options | 25W, 50W / 1A, 3A, 7A |
| Carburetor | Butterfly |
| Ignition System | Transistorized magneto |
| Starting System | Recoil Starter |
| Lubrication System | Splash |
| Governor System | Centrifugal Mechanical |
| Air cleaner | Dual Element |
| Oil Capacity | 0.61 US qt. (0.58 L) |
| Fuel Tank Capacity | 3.3 U.S. qts (3.1 liters) |
| Fuel | Unleaded 86 octane or higher |
| Dry Weight | 33 lbs. (15.1 kg) |
| Dimensions | |
| Length (min) | 12.2 (312 mm) |
| Width (min) | 14.3 (362 mm) |
| Height (min) | 13.6 (346 mm) |
COMMON APPLICATIONS:
- Pressure washers
- Power Trowels
- Commercial lawn and garden equipment
- Tillers / cultivators
- Generators
- Construction / industrial equipment
- Agricultural equipment
- Water pumps
*The SAE J1349 standard measures net horsepower with the manufacturer's production muffler and air cleaner in place. Net horsepower more closely correlates with the power the operator will experience when using a Honda engine powered product. The power rating of the engines indicated in this document measures the net power output at 3600 rpm (7000 rpm for model GXH50, GXV50, GX25 and GX35) and net torque at 2500 rpm, as tested on a production engine. Mass production engines may vary from this value. Actual power output for the engine installed in the final machine will vary depending on numerous factors, including the operation speed of the engine in application, environmental conditions, maintenance and other variables.
